3. Operation
Fieldbus Communication
87
RCP6
3.2.2 Parameter Settings (Setting on RC PC Software)
Parameter data should be set appropriately according to the applicaiton requirements.
Parameters are variables to be set to meet the use of the controller in the similar way as
settings of the ringtone and silent mode of a cell phone and settings of clocks and calendars.
(Example)
Software Stroke Limit : Set a proper operation range for definition of the stroke end, prevention
of interferences with peripherals and safety.
Zone Output : Set to require signal outputs in an arbitrary position zone within the
operation zone.
Parameter settings are to be established with RC PC software (Ver.10.2.0.0 or later) or teching
box TB-02/TB-02D (Ver. 1.00 or later) TB-01/TB-01D/TB-01DR/CON-PTA/CON-PDA/
CON-PGA (S) (Ver.2.60 or later).
Parameters should be set to meet the use of the controller prior to operation. Once set, they
may not set every operation.
Refer to Chapter 8 Parameter for the parameter types and the details.
