IAI RCP6S User Manual

1. Specications Check
Fieldbus Communication
35
RCP6
S
1.4.6 Specifications of PROFINET-IO Interface
Item Specification
Communication Protocol IEC61158 (IEEE802.3), IEC61784
Baud Rate 100Mbps
Number of Occupied Bytes 3.4.1 PLC Address Construction by each Operation Mode
Communication Cable Length Distance between each segment: 100m Max.
Number of Connection Follows master unit
Available Node Addresses for Setting 0.0.0.0 to 255.255.255.255
Communications Cable
(Note 1)
Category 5 or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 connector × 1pc
GSDML File Version Ver 2.3
Note 1 Prepare separately for the communication cable.
