1. Speciîš¿cations Check
Fieldbus Communication
38
RCP6
S
1.5.3
RCP6S Gateway Controller
Dimensions for RCM-P6PC, RCM-P6AC and RCM-P
6DC should be the sa
me.
[1]
Fixed Screws T
ype
[2]
Attachment DIN Rail
T
ype
35.4 (Width of 35mm DIN rail)
66.5 from DIN rail center
30
115
(6.5)
58
8.5
ME0349-4B
49
51
