1. Specications Check
Fieldbus Communication
34
RCP6
S
1.4.3 Specifications of PROFIBUS-DP Interface
Item Specification
Communication Protocol PROFIBUS-DP
Baud Rate Automatically follows the master
Communication System Hybrid System (Master-slave system or token passing system)
Number of Occupied Stations Refer to 3.4.1 PLC Address Construction by Each Operation Mode
MAX. Total Network Baud Rate Cable Type
100m 3,000/6,000/12,000kbps
200m 1,500kbps
400m 500kbps
1000m 187.5kbps
Communication Cable Length
1200m 9.6/19.2/93.75kbps
Type A cable
Communications Cable Equipped with shield twist pair cable AWG18
Connector
(Note 1)
9-pin female D-sub connector
Transmission Path Format Bus/Tree/Star
Note 1 Please prepare a 9-pin male D-sub connector for the cable-end connector.
1.4.4 Specifications of EtherNet/IP Interface
Item Specification
Communication Protocol IEC61158 (IEEE802.3)
Baud Rate 10BASE-T/100BASE-T (Autonegotiation setting is recommended)
Number of Occupied Bytes 3.4.1 PLC Address Construction by each Operation Mode
Communication Cable Length
Follows EtherNet/IP specifications
(Distance between hub and each node: 100m max.)
Number of Connection Follows master unit
Available Node Addresses for Setting 0.0.0.0 to 255.255.255.255
Communications Cable
(Note 1)
Category 5 or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 connector × 1pc
Note 1 Prepare separately for the communication cable.
1.4.5 Specifications of EtherCAT Interface
Item Specification
Communication Protocol IEC61158 type 12
Physical Layer 100Base-TX (IEEE802.3)
Baud Rate Automatically follows the master
Number of Occupied Bytes 3.4.1 PLC Address Construction by each Operation Mode
Communication Cable Length Follows EtherCAT® specifications (Distance between each node: 100m max.)
Slave Type I/O slave
Available Node Addresses for Setting 0 to 65535
Communications Cable
(Note 1)
Category 5 or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 connector × 2pcs (Input × 1, Output × 1)
Connect Daisy chain only
Note 1 Prepare separately for the communication cable.
ME0349-4B
