3. Operation
Fieldbus Communication
155
RCP6
4) Tool Communication Setting
• Port : Set the communication port number.
• Baudrate (bps) : Select the baud rate between RCP6S GW and PC from
9600/19200/38400/57600/115200/230400.
5) Time Setting
By selecting Time on PC, the current time on the PC is acquired and set to RCP6S GW.
If Set Manually is selected, desired time set in the clock edit in the window can be set in RCP6S
GW. Click “Write”, and the time setting is transferred to RCP6S GW and the data is written in.
Clicking on the Confirm button and the clock data currently retained in RCP6S GW can be read
and displayed.
Caution: The clock (calendar) function in RCP6S GW can be retained for approximately 10 days
(reference) after the power to RCP6S GW is turned OFF.
Once the clock data is lost, the time passed since the power is turned back on as
2000/1/1 0:00:00 is displayed as the current time.
3.8.3
