7.
Absolute Reset
Fieldbus Communication
182
RCP6
S
[2]
For T
eaching Pendant (TB-02/TB-03)
Press
Reset Alm
.
Press
T
rial Operation
on the Menu 1 screen.
Press
Jog_Inching
on T
rial screen.
T
o
uch Servo
to turn the servo O
N and tou
ch
Homing
in
Jog/Inching screen.
1
2
3
4
ME0349-4B
193
195
