8. Parameter
Fieldbus Communication
197
RCP6
[17] Default movement direction for excitation-phase signal
detecting movement (Parameter No.28)
No. Name Symbol Unit Input Range
Default factory
setting
28
Default Movement Direction for
Excitation-phase Signal Detection
PHSP –
0 : Reversed
direction
1 : Forward
direction
In accordance
with actuator
Excitation detection
(Note)
starts when the servo is turned ON for the first time after the power is
supplied. Define the detection direction at this time.
Even though it is generally unnecessary to change this setting, set this to the direction which
the motor is easy to move when the actuator interferes with the mechanical end or peripheral
object at the time the power is supplied.
If the direction not interfering is the same direction as the home return direction, set the same
values as set to Parameter No.5 Home Return Direction. If the direction is opposite, set the
other values from Parameter No.5. (If No.5 is 0, set 1. If No.5 is 1, set 0.)
Note 1 For Simple Absolute Type, the excitation detection is performed at the end of home
return operation.
[18] Excitation-phase signal detection time (Parameter No.29)
No. Name Symbol Unit Input Range
Default factory
setting
Specifications
1 to 999 10
RCP6S
RCM-P6PC
29
Excitation-phase Signal
Detection Time
PHSP msec
50 to 999 128 RCM-P6AC
Excitation detection
(Note)
starts when the servo is turned ON for the first time after the power is
supplied. Define the detection direction at this time.
Even though it is generally unnecessary to change this setting, changing the setting of this
parameter may be effective when excitation error is generated or abnormal operation is
confirmed.
Please contact us in the case a change is necessary to this parameter.
Note 1 For Simple Absolute Type, the excitation detection is performed at the end of home
return operation.
For RCP6S, RCM-P6PC
and RCM-P6AC only
For RCP6S, RCM-P6PC
and RCM-P6AC only
To Next Page
