Chapter 9 Troubleshooting
247
Chapter 9 Troubleshooting
9.1 Action to Be Taken upon Occurrence of Problem
Upon occurrence of a problem, take an appropriate action according to the procedure below in
order to ensure quick recovery and prevent recurrence of the problem.
1) Check the status indicator LEDs on the controller.
LED Indication Status
Green Light is turned ON. System ready (normal CPU operation)
PWR
OFF Power OFF
Green Light is turned ON. Servo ON (operation available)
Flashing in Green Automatic servo is OFF
SV
OFF Servo OFF
ALM Orange Light is turned ON.
Alarm being generated
(operation release or cold start level alarm)
EMG Red Light is turned ON. Emergency stop (regardless of alarms)
WRG
(Note1)
Flashing in Orange Warning being generated (Refer to 9.1.1)
2) Check whether an alarm occurs on the host controller (PLC, etc.).
3) Check the voltage of the main power supply.
4) Check the voltage of power supply for the PIO.
5) Check the voltage of the power supply for brake (For the actuator with the brake).
6) Alarm Check
(Note2)
Check the alarm code on the teaching tool such as PC software.
7) Check the connectors for disconnection or connection error.
8) Check the cables for connection error, disconnection or pinching.
Before performing a continuity check, turn off the power (to prevent electric shocks) and
disconnect the cables of measuring instruments (to prevent accidental power connection
due to sneak current path).
9) Check the I/O signals.
Using the host controller (PLC, etc.) or a teaching tool such as PC software, check the
presence of inconsistency in I/O signal conditions.
10) Check the noise elimination measures (grounding, installation of surge killer, etc.).
11) Check the events leading to the occurrence of problem
(Note 2)
, as well as the operating
condition at the time of occurrence.
12) Analyze the cause.
13) Treatment
Note1: Dedicated for SCON-CAL/CGAL LED
Note2: If parameter No. 111 (Selection of using calendar function) is set to “1” (use), it is
possible to know the date and time at which the alarm occurred.
Set the date and time from the teaching tool such as PC software at the first
power-on of the controller.
The date and time data set once is retained for about 10 days if the power supply
of the controller is OFF. Unless the setting is conducted or the clock data is lost,
the clock shows 00/01/01 00:00:00 when the power is turned ON. Even if the date
and time data is lost, the generated error code is retained.
Alarms subject to this function only include those in 9.4 Alarm but do not include
errors in the teaching tool such as PC software.
Notice:
In troubleshooting, exclude normal portions from suspicious targets to narrow down
the causes. Check 1) to 11) described above before contacting us.
