1.1.3 Instruction Manuals Related to this Product, which are Contained in the
Instruction Manual (DVD).
No. Name Manual No.
1 SCON-CA/CAL/CGAL Controller Instruction Manual ME0243
2
PC Software
RCM-101-MW/ RCM-101-USB Instruction Manual
ME0155
3
Touch Panel Teaching to Apply for TB-01/01D/01DR Position Controllers
Instruction Manual
ME0324
4 Touch Panel Teaching CON-PTA/PDA/PGA Instruction Manual ME0295
5 Touch Panel Teaching CON-PT/PD/PG Instruction Manual ME0227
6 Teaching Pendant CON-T/TG Instruction Manual ME0178
7 DeviceNet (High Performance Type) Instruction Manual ME0256
8 CC-Link (High Performance Type) Instruction Manual ME0254
9 PROFIBUS-DP (High Performance Type) Instruction Manual ME0258
10 CompoNet (High Performance Type) Instruction Manual ME0220
11 MECHATROLINK (High Performance Type) Instruction Manual ME0221
12 EtherCAT Instruction Manual ME0273
13 EtherNet/IP Instruction Manual ME0278
14 PROFINET IO Instruction Manual ME0333
15 MECHATROLINK-Ⅲ Instruction Manual ME0317
16 Instruction Manual for the Serial Communication [for Modbus] ME0162
17 ROBONET Instruction Manual ME0208
1.1.4 How to Read the Model Plate
[1] SCON-CA, SCON-CAL/CGAL (side surface)
[2] SCON-CAL/CGAL (top surface)
(Note) The contents of display may be different depending on the series and types, and some
items may not be displayed.
MODEL : SCON-CA-60A-NP-2-1
SERIAL No. : 800056144 L11
INPUT : 1 φ, 100-115v, 50/60Hz, 0.9A
OUTPUT : 3 φ, 0-135v, 0-333Hz, 0.70A
Model
Serial numbe
r
SCON-CAL-20I-NP-0-1
SERIAL No. : 800056144 A1
Model
Serial numbe
r
