1.1.5 How to Read the Model of the Controller
(Note 1) Specified only for SCON-CA
S C O N
–
C A
–
2 0 I H A -NP-3-1
–
D N - **
<Series>
<Type>
CA : High Performance Type
CAL : Small Type
CGAL : Small Safety Category
Complied Type
<Actuator Characteristics>
[Motor Type]
* For SCON- CAL/CGAL,
200W or Less
(Connection not available to also
100S and 200S)
12 : 12W
20 : 20W
30D : 30W (Excluding RS)
30R : 30W (for RS)
60 : 60W
100 : 100W
100S : 100W (LSA)
150 : 150W
200 : 200W
200S : 200W (LSA/DD)
300S : 300W (LSA)
400 : 400W
600 : 600W
750 : 750W
750S : RCS2-RA13R with Loadcell
<Encoder Type>
I : Incremental
A : Absolute
G : Spurious Absolute
(Note 1)
<Option>
Not Indication : Standard Type
HA : High Accel/Decel Type
I : Index Absolute Type (DD)
(Note 1)
M : Multi-Rotation Absolute Type (DD)
(Note 1)
Identification for IAI use only
* There is no identification in some cases.
<
Type of Installation
(dedicated for SCON-CAL/CGAL) >
(Not Specified) : Screw Attachment Type
DN : DIN Rail Mounting Type
<Power-supply Voltage>
1 : Single-phase 100V AC
2 : Single-phase 200V AC
<I/O Cable Length>
0 : Equipped with no cable
2 : 2m (Standard)
3 : 3m 5 : 5m
<I/O Signal Pattern>
NP : NPN Type (Sync. Type) (Standard)
PN : PNP Type (Source Type)
DV : DeviceNet Connection Type
ML : MECHATROLINK-Ι/ΙΙ Connection
Type
CC : CC-Link Connection Type
PR : PROFIBUS-DP Connection Type
CN : CompoNet Connection Type
ML : MECHATROLINK Ι, ΙΙ Connection
Type
ML3 : MECHATROLINK ΙΙΙ (Motion)
Connection Type
(Note 1)
EC : EtherCAT Connection Type
EP : EtherNet/IP Connection Type
PRT : PROFINET-IO Connection Type
