Chapter 2 Wiring
66
[6] Regenerative Units Circuit
SCON
RB
Regenerative
Units Connector
Regenerative Units
REU2 (RESU-2, RESUD-2)
Regenerative Units
REU1 (RESU-1, RESUD-1)
CB -SC - REU010
CB -ST
RB IN
RB OUT
RB IN
RB OUT
-REU010
