[2] Format Settings for Feedback Pulse
Set the format of output pulse in Parameter No.69 and active high/low in No.70.
(1) Feedback Pulse Train
No. Name Symbol Unit
Input
Range
Initial
Value
69 Feedback Pulse Train FBPT – 0 to 2 0
(2) Feedback Pulse Form Polarity
No. Name Symbol Unit
Input
Range
Initial
Value
70 Feedback Pulse Form Polarity FBPT – 0 to 1 0
0: Disable
1: Enable
AFB•/AFB
BFB•/BFB
AFB•/AFB
BFB•/BFB
AFB•/AFB
BFB•/BFB
AFB•/AFB
BFB•/BFB
AFB•/AFB
BFB•/BFB
AFB•/AFB
BFB•/BFB
ZFB•/ZFB
High Low
High Low
2
1
0
2
1
0
Normal Rotation
Pulse String
Normal Rotation
Pulse String
Reverse Rotation
Pulse String
Reverse Rotation
Pulse String
The normal rotation pulse string shows the motor rotation amount in normal direction, and reverse
rotation pulse string shows the motor rotation amount in reverse direction.
Pulse Train
Pulse Train
Symbol
Symbol
The command pulse shows the motor rotation amount and the command symbol shows the
rotation direction.
A/B Phase
Pulse String
A/B Phase
Pulse String
The A/B Phase 4-fold Pulse with the phase difference of 90° shows the commands for
the rotation amount and direction.
Command Pulse
String Mode
Input
Terminal
In Normal Rotation
In Reverse Rotation
Setting Value
of Parameter
No. 69
Negative LogicPositive Logic
When the actuator encoder is other than the serial encoder, the Z-phase
signal is output as it is. In the case of serial encoder, the range of ±0.5°
of mechanical angle from the point 0 position (origin), is output as
the Z-phase signal.
Only when the motor rpm is 100rpm or less, this accuracy can be
guaranteed for the communication frequency with the encoder.
* When the encoder pulse count is 16384 (Pulse/rev), it shows the serial
encoder.
