Chapter 1 Specifications Check
1.1 Product Check
1.1.1 Parts
This product is comprised of the following parts if it is of standard configuration.
If you find any fault in the contained model or any missing parts, contacts us or our distributer.
No. Part Name Model Remarks
1 Controller
Refer to “How to read the model plate”, “How to
read the model of the controller”.
Accessories
2 I/O Flat Cable CB-PAC-PIO***
***shows the
cable length
(Example)
*** : 020 = 2 [m]
3
Service Connector for
Pulse Train Control
Plug : 10114-3000PE (Supplier : 3M)
Shell : 10314-52F0-008 (Supplier : 3M)
Enclosed in
SCON-CA
4 System I/O Plug FMC1.5/4-ST-3.5 (Supplier : Phoenix Contact)
5 Brake Power Supply Plug MC1.5/2-ST-3.5 (Supplier : Phoenix Contact)
Applicable Cable
Size 0.5mm
2
(AWG20)
6 AC Power Supply Plug MSTB2.5/6-STF-5.08 (Supplier : Phoenix Contact)
Applicable Cable
Size 2.0mm
2
(AWG14)
7 Absolute Battery AB-5
Enclosed in
Absolute Type
8 Dummy Plug DP-5
Enclosed in
SCON- CGAL
9 First Step Guide
10 Instruction Manual (DVD)
11 Safety Guide
1.1.2 Teaching Tool
A teaching tool such as PC software is necessary when performing the setup for position
setting, parameter setting, etc. that can only be done on the teaching tool.
Please prepare either of the following teaching tools such as PC software.
No. Part Name Model
1
PC Software
(Includes RS232C Exchange Adapter + Peripheral Communication Cable)
RCM-101-MW
2
PC Software
(Includes USB Exchange Adapter + USB Cable + Peripheral Communication Cable)
RCM-101-USB
3 Touch Panel Teaching TB-01
4 Touch Panel Teaching (with deadman switch attached on the left) TB-01D
5 Touch Panel Teaching (with deadman switch attached on the right) TB-01DR
6 Touch Panel Teaching CON-PTA
7 Touch Panel Teaching (with deadman switch) CON-PDA
8
Touch Panel Teaching
(with deadman switch + TP adapter (RCB-LB-TGS))
CON-PGAS
