Actuator Axes
Refer to the pictures below for the actuator axes that can be controlled by SCON-CA.
0 defines the home position, and items in ( ) are for the home-reversed type (option).
Caution : There are some actuators that are not applicable to the origin reversed type. Check
further on the catalog or the Instruction Manual of the actuator.
(1) Rod Type
(2) Slider Type
(3) Flat Type
(4) Arm Type
