IAI SCON-CA - Name for each Parts and Their Functions

14
Name for Each Parts and Their Functions
SCON-CA
2) Power Supply
Connector
4) Regeneration Unit
Connecting Connector
3) Motor Connector
5) System I/O Connector
6) Operation Mode
Changeover Switch
7) Axis Number
Setting Switch
8) Status Indicator
LEDs
1) FG Connection
Terminal
10) PIO Connector
9) Connector for Pulse
Train Control
12) SIO Connector
11) Operation Mode
Setting Switch
13) Brake Release Switch
14) Brake Power Supply
Connector
15) Encoder Connector
16) Absolute Battery
Connector
17) Absolute Battery
Holder
