Chapter 2 Wiring
46
2.1.2 PIO Pattern Selection and PIO Signal
(1) PIO Pattern (Control Pattern) Selection
SCON-CA Controller possesses 8 types of control logics, PIO Patterns 0 to 7, while
SCON-CAL/CGAL Controller possesses 6, PIO Patterns 0 to 5. Set the most suitable PIO
pattern with the actual use to Parameter No. 25 “PIO Pattern Select”.
Refer to “3.2 Operation in Positioner Mode” for the details of PIO patterns.
Selectable PIO Patterns for SCON-CA and SCON-CAL/CGAL
Type
Value set in
parameter
No. 25
Mode Overview
PIO
Pattern 0
0
(at the
delivery)
Positioning Mode
(Standard Type)
• Number of positioning points : 64 points
• Position command : binary code
• Zone signal output
*1
: 1 point
• Position zone signal output
*2
: 1 point
PIO
Pattern 1
1
Teaching mode
(Teaching type)
• Number of positioning points : 64 points
• Position command : binary code
• Position zone signal output
*2
: 1 point
• Jog operation enabled by PIO signal
• Writing current position data to position table
enabled by PIO signal
PIO
Pattern 2
2
256-point mode
(
Number of
positioning points :
256-point type)
• Number of positioning points : 256 points
• Position command : binary code
• Position zone signal output
*2
: 1 point
PIO
Pattern 3
3
512-point mode
(
Number of
positioning points :
512-point type)
• Number of positioning points : 512 points
• Position command : binary code
• Zone signal output : None
PIO
Pattern 4
4
Solenoid Valve
Mode 1
(7-point type)
• Number of positioning points : 7 points
• Position command : Individual number signal ON
• Zone signal output
*1
: 1 point
• Position zone signal output
*2
: 1 point
PIO
Pattern 5
5
Solenoid Valve
Mode 2
(3-point type)
• Number of positioning points : 3 points
• Position command : Individual number signal ON
• Completion signal : Signal equivalent to LS
(limit switch) enabled
• Zone signal output
*1
: 1 point
• Position zone signal output
*2
: 1 point
