Chapter 2 Wiring
47
Selectable PIO Patterns for SCON-CA
Type
Value set in
parameter
No. 25
Mode Overview
PIO
Pattern 6
6
Pressing
Operation Using
Force Sensor
Mode 1
• Number of positioning points : 32 points
• Position command : binary code
• Position zone signal output
*2
: 1 point
• Judgment of pressing force enabled
PIO
Pattern 7
7
Pressing
Operation Using
Force Sensor
Mode 2
(Solenoid Valve Type)
• Number of positioning points : 5 points
• Position command : Individual number signal ON
• Position zone signal output
*2
: 1 point
• Judgment of pressing force enabled
*1 Zone signal output : Set the zone range in parameter No.1 and 2. The signal is
always effective after home return is completed.
*2 Position zone signal output : This feature is associated with the specified position number.
The zone range is set in the position table. The zone range is
enabled only when the position is specified but disabled if
another position is specified.
Position Zone Signal can be changed to Zone Signal in
Parameter No.149.
