IBM DS5100 User Manual

Table 47. RAID controller LEDs (continued)
Legend LED Color Normal Status Problem Status Procedure
3 Drive Port Bypass
(one LED per port)
Note: The drive
channel consists of
two FC ports. This
LED indicates the
drive port bypass
status of one of the
two FC ports that
made up a drive
channel. The LED
marked 6 shows
the status of the
other port.
Amber LED Off On = Bypass
problem
v An SFP module
is inserted in the
port and the
connected fibre
channel is either
absent or not
properly
connected.
v The storage
expansion
enclosure
connected to this
port is not
powered on.
v There is a
problem with the
fibre channel
connection
between this port
and the fibre
channel port of
the connected
ESM in the
storage
expansion
enclosure.
4 Drive Channel
Speed – L1
Green LED See Table 48 on page 149.
5 Drive Channel
Speed – L2
Green LED
Chapter 4. Operating the storage subsystem 147
