Table 4. Firmware Error Codes. (continued)
Error Code Description Action/
Possible Failing FRU
20E0 0009 Invalid password entered - system locked The password has been entered incorrectly 3
times.
Turn off, then turn on the system unit, then
enter the password correctly.
20EE 0003 IP parameter requires 3 dots ″.″ Enter valid IP parameter.
Example: 000.000.000.000
20EE 0004 Invalid IP parameter Enter valid IP parameter.
Example: 000.000.000.000
20EE 0005 Invalid IP parameter (>255) Enter valid IP parameter.
Example: 255.192.002.000
20EE 0007 Keyboard not found
1. Plug in keyboard.
2. Replace the CEC backplane.
Location: U0.1-P1
20EE 0008 No configurable adapters were found in the
system by the remote IPL menu in the SMS
utilities.
This warning occurs when the remote IPL menu
in the SMS utilities cannot locate any LAN
adapters that are supported by the remote IPL
function. If a supported device is installed:
1. Replace the adapter.
2. Go to “MAP 1542: I/O Problem Isolation” on
page 127.
20EE 0009 Unable to communicate with the service
processor.
Replace the CEC backplane
Location: U0.1-P1.
20EE 000A The image size on the boot or installation
device exceeds the system firmware memory
limitations.
1. Check for system firmware updates. Apply if
available.
2. Call service support.
20EE 000B The system was not able to find an operating
system boot record on the devices listed in the
boot list.
This can be caused by the wrong devices being
in the boot list, a problem that prevents the
system from communicating with the device
that contains the boot record, or the boot record
being corrupted.
Go to “Boot Problems/Concerns” on page 204.
232 Eserver pSeries 630 Model 6C4 and Model 6E4 Service Guide
