Identifying the Terminal Type to the Diagnostics
When you run diagnostics, you must identify which type of terminal you are using. If the terminal type is
not known when the FUNCTION SELECTION menu is displayed, the diagnostics do not allow you to
continue until a terminal is selected from the DEFINE TERMINAL option menu.
Undefined Terminal Types
If you specify an undefined terminal type from the DEFINE TERMINAL option menu, the menu prompts the
user to enter a valid terminal type. The menu redisplays until either a valid type is entered or you exit the
DEFINE TERMINAL option. For a system attached to an HMC use VT320 emulation. If the AIX operating
system is being used, from the command line, type: export term=vt320
Resetting the Terminal
If you enter a terminal type that is valid (according to the DEFINE TERMINAL option menu) but is not the
correct type for the Hardware Management Console (HMC) virtual terminal window being used, you may
be unable to read the screen, use the function keys, or use the Enter key. To bypass these difficulties,
press Ctrl-C to reset the terminal. The screen display that results from this reset depends on the mode in
which the system is being run:
v Online Normal or Maintenance Mode - The command prompt displays.
v Standalone Mode or Online Service Mode - The terminal type is reset to dumb, the Diagnostic Operating
Instruction screen displays, and you are required to go through the DEFINE TERMINAL process again.
Online Diagnostics Modes of Operation
Notes:
1. When running online diagnostics on a partition in a partitioned system, diagnostics can be run only on
resources that are allocated to that partition.
2. Online diagnostics can only be run in a partition with AIX installed.
The online diagnostics can be run in the following modes:
v Service Mode
v Concurrent Mode
v Maintenance Mode
Service Mode
Service mode provides the most complete checkout of the system resources. This mode also requires that
no other programs be running on the partition or on a full system partition. Except for the SCSI adapter
and the disk drives used for paging, resources on all partitions or systems on a full system partition can be
tested. However, note that the memory and processor are only tested during POST, and the results of the
POST tests are reported by diagnostics.
Error-log analysis is done in service mode when you select Problem Determination on the DIAGNOSTIC
MODE SELECTION menu.
Consider the following when you run the online diagnostics from a server or a disk:
v The diagnostics cannot be loaded and run from a disk until the AIX operating system has been installed
and configured.
v The diagnostics cannot be loaded on a system (client) from a server if that system is not set up to boot
from a server over a network. When the system is set up to boot from a server, the diagnostics are run
in the same manner as they are from disk.
354 Eserver pSeries 630 Model 6C4 and Model 6E4 Service Guide
