Modem Configuration Menu
Note: This option applies only to a modem attached to serial port 1 (S1) or serial port 2 (S2) on the CEC
backplane.
The first two lines of the Modem Configuration Menu contain status of the current selections. Selections
are made in the sections labeled Modem Ports and Modem Configuration File Name. Select the serial port
that you want to activate and then select the modem configuration file for the modem on the port. If you
want to set up all of the serial ports with modems, make your selections one port at a time.
Modem Configuration Menu
Port 1 Modem Configuration File Name:
Port 2 Modem Configuration File Name:
To make changes, First select the port and then the configuration file
name
Modem Ports:
1. Serial port 1
2. Serial port 2
Modem Configuration File Name:
5. none9. modem_z_sp
6. modem_f_sp 10. modem_m1_sp
7. modem_f0_sp 11. modem_m0_sp
8. modem_f1_sp 12. modem_m1_sp
30. Save configuration to NVRAM and Configure modem
98. Return to Previous Menu
0>
For information on choosing a modem configuration file, see “Sample Modem Configuration Files” on
page 597 and “Transfer of a Modem Session” on page 601.
Serial Port Selection Menu
This menu allows you to enable or disable the call-in and call-out functions of each serial port in any
combination.
Note: Call-out is disabled in partitioned systems.
Serial Port Selection Menu
1. Serial Port 1 Call-Out:
Currently Disabled
NOT supported in LPAR mode
2. Serial Port 2 Call-Out:
Currently Disabled
NOT supported in LPAR mode
3. Serial Port 1 Call-In:
Currently Disabled
4. Serial Port 2 Call-In:
Currently Disabled
98. Return to Previous Menu
0>
Chapter 7. Using the Service Processor
387
