Specifications
This section contains system specifications for both Model 6C4 and Model 6E4.
Note: Refer to the 7014 Series Model T00 and T42 Rack Installation and Service Guide, order number
SA38-0577, for information on cabling power from the rack to the I/O subsystem.
Dimensions Rack (Model 6C4) Tower (Model 6E4)
Height 176 mm 6.9 in. 544.0 mm (21.42 in.)
4 EIA Units
Width 448 mm 17.5 in. 308.0 mm (12.13 in.) 191 mm without
legs
Depth 816 mm 32.13 in. - Includes 145 mm
for cable management arm
789.0 mm (31 in.) - Includes 70 mm
for rear acoustic cover
Weight
Minimum configuration 32.0 kg 70.4 lbs. 36.0 kg 79.2 lbs.
Maximum configuration 47.3 kg 104.0 lbs. 51.0 kg 112.2 lbs.
Electrical
Power source loading (maximum in
kVA)
1.20
Power source loading (typical in kVA) 0.75
Voltage range (V ac) 100-127 Vac or 200-240 Vac (single phase)
Frequency (hertz) 50 / 60
Thermal output (maximum) 2540 Btu/hr
Thermal output (typical) Btu/hr
Power Requirements (minimum load) 350 watts
Power Requirements (maximum load) 670 watts
Power factor - U.S., World Trade,
Japan
0.95
Inrush current¹ 75/amps (maximum at <10ms)
25/amps (maximum at 10ms - 150ms)
Note: The above amps are held for the full input range of 180 V/ac to 259
V/ac and 47 to 63 Hz.
Maximum Altitude², ³ 2135 m (7000 ft.)
Temperature Requirements Operating
5 to 35°C
(41 to 95°F)
Storage
1 to 60°C
(34 to 140°F)
Humidity Requirements Operating Storage
(Noncondensing) 8 to 80% 5 to 80%
Wet Bulb 27°C (80°F) 27°C (80°F)
Model 6E4 Noise Emissions⁴ Operating Idle
L
WAd
6.0 bels 5.9 bels
<L
pA
>
m
42 dBA 41 dBA
Model 6C4 Noise Emissions⁴ Operating Idle
L
WAd
6.1 bels 6.0 bels
<L
pA
>
m
44 dBA 43 dBA
46 Eserver pSeries 630 Model 6C4 and Model 6E4 Service Guide
