PD value Size
68 256 MB
78 1024 MB
88 2048 MB
Note: Memory DIMMs must be installed in quads.
Error Log Utility Procedure
When the System Management Services menu appears, check the error log for any errors. Use the
location code obtained from the SMS error log utility to identify the component the error is reported
against. To obtain the location code from the error log utility do the following:
1. From the SMS main menu, choose View Error Log.
2. If an error is logged, check the time stamp.
3. If the error was logged during the current boot attempt, record it.
4. Look up the error in the Chapter 5, “Error Code to FRU Index”, on page 209 and perform the listed
action.
5. If no recent error is logged in the error log, go to “MAP 1548: Processor Subsystem Problem Isolation”
on page 139.
System Firmware Update Messages
Error Code Description Action/
Possible Failing FRU
A1FD 0000 Recovery mode entered Information message
A1FD 0001 Service processor flash recovery Insert Diskette #1
A1FD 0002 Service processor flash recovery Insert Diskette #2
A1FD 0003 Service processor flash recovery Insert Diskette #3
A1FD 0004 Service processor flash recovery Insert Diskette #4
Scan Dump Messages
Error Code Description Action/ Possible Failing FRU
A100 3000 Successful completion of scan dump Informational message; may or may
not be seen during a scan log dump.
A1FF 3000 Scan dump has been disabled Informational message; may or may
not be seen during a scan log dump.
Common Firmware Error Codes
Attention: Follow the procedure defined in “Checkpoint and Error Code Index” on page 213. If you
replace FRUs or perform an action and the problem is still not corrected, go to “MAP 1548: Processor
Subsystem Problem Isolation” on page 139 unless otherwise indicated in the tables.
If you replace FRUs and the problem is corrected, go to ″MAP 0410: Repair Checkout″ in the RS/6000
Eserver pSeries Diagnostic Information for Multiple Bus Systems.
Chapter 5. Error Code to FRU Index 335
