Table 4. Firmware Error Codes. (continued)
Error Code Description Action/
Possible Failing FRU
2602 0012 Description: PCI device run-time error, bridge in freeze state
Action: If the location code identifies a slot:
1. Check the cabling to the adapter, in particular, the adapters that have serial ports. Serial ports
may require null modems or special cabling configurations to avoid connecting driver outputs
together. This may create a PCI slot power problem and force the adapter to be
deconfigured.
Attention: Before moving the adapter to another slot, verify with the customer or system
administrator that the slot that the adapter is being moved to is available to the partition in
which the adapter presently resides.
2. Move adapter to another slot (behind a different PCI bus).
3. Check for available firmware updates for adapter. Apply update if available.
4. Replace the adapter.
5. Check for system firmware updates. Apply if update available.
6. If the card is in the system drawer, replace the PCI riser card, location: U0.1-P2. If the card is
in an I/O subsystem, replace the I/O backplane that contains the slot in which the adapter
was originally installed, location: U0.dd-P1.
2602 0014 A PCI adapter is not properly seated, or an
invalid type of PCI adapter is installed in the
system.
If the location code identifies a slot:
1. Check the PCI adapter specified by the
location code for proper seating.
2. Verify that the PCI adapter specified by the
location code is supported on this system.
3. Replace the adapter.
If the location code identifies an I/O planar:
1. Check for system firmware updates. Apply
the update if one is available.
2. Replace the I/O planar.
2602 0Fxy PCI bridge chip failure Replace the I/O planar specified by the location
code. The I/IO planar may be in the CEC or in
an external I/O drawer.
2680 0Axy MX-PCI bridge BIST failure The problem is associated with bridge ″y″ in I/O
drawer ″x.″
Replace the I/O backplane in I/O drawer ″x.″
Location U0.x-P1
See “Determining Location Code” on page 211
or location code information related to this error.
2680 0Cxx Machine check occurred
1. Replace the part identified by the location
code associated with this error code.
2. If the location code associated with this
error code identifies an adapter, and
replacing the adapter does not correct the
problem, replace the PCI riser card
Location: U0.1-P2 or U0.dd-P1
2680 0Dxx Machine check occurred; unable to isolate to a
single device
Go to “MAP 1542: I/O Problem Isolation” on
page 127
246 Eserver pSeries 630 Model 6C4 and Model 6E4 Service Guide
