To change IP parameters, type the number of the parameters for which you want to change the value.
Entering IP parameters on this screen will automatically update the parameters on the ping test screen.
Attention: If the client system and the server are on the same subnet, set the gateway IP address to
[0.0.0.0].
Selecting the Adapter Configuration allows the setting of the network speed, enabling or disabling
spanning tree, and setting the protocol as shown in the following menu example:
Adapter Configuration
10/100 Mbps Ethernet PCI Adapter II: U0.1-P1/E1
1. Speed, Duplex
2. Spanning Tree Enabled
3. Protocol
--------------------------------------------------------------------------------------------------
Navigation keys:
M = return to main menu
ESC key = return to previous screen X = eXit System Management Services
--------------------------------------------------------------------------------------------------
Type the number of the menu item and press Enter or Select a Navigation key: _
Selecting the Speed, Duplex option allows you to set the interface speed at which the card will run and
half versus full duplex. The current setting is indicated by ″<===″.
Adapter Configuration
10/100 Mbps Ethernet PCI Adapter II: U0.1-P1/E1
1. auto, auto
2. 10,half
3. 10,full
4. 100,half
5. 100,full
--------------------------------------------------------------------------------------------------
Navigation keys:
M = return to main menu
ESC key = return to previous screen X = eXit System Management Services
--------------------------------------------------------------------------------------------------
Type the number of the menu item and press Enter or Select a Navigation key: _
Chapter 8. Using System Management Services
411
