Index Number FRU Part
Number
Units Per
Assembly
Description
1 21P4312 1 Cable Management Arm Assembly (Model 6C4 Only)
2 00P2806 1 Cable Carrier Support Bracket (Model 6C4 Only)
3 00P2807 1 Rack Flange Mounting Bracket (Model 6C4 Only)
4
00P2974 1 Processor Assembly, 1.0 GHz, 1-way
00P2977 Up to 2 Processor Assembly, 1.0 GHz, 2-way
00P2728 1 Processor Assembly, 1.2 GHz, 1-way
00P2731 Up to 2 Processor Assembly, 1.2 GHz, 2-way
00P2733 1 Processor Assembly, 1.45 GHz, 1-way
00P2736 Up to 2 Processor Assembly, 1.45 GHz, 2-way
5
53P3224 Up to 16 256 MB DIMMs
53P3226 Up to 16 512 MB DIMMs
53P3230 Up to 16 1 GB DIMMs
53P3232 Up to 16 2 GB DIMMs
6
00P3203 1 per RIO
connector
RIO Connector Cover (only available on Model 6C4 that
has not been upgraded to support an I/O subsystem)
7
00P4488 1
CEC Backplane
00P5830 1
8 09P5866 2 Units PCI Cooling Fans (2 Fans per Unit)
9 N/A 1 Internal Cable Management bracket
9a 00P4885 1 RIO Cable Support Bracket
10 N/A 1 Chassis
11 00P4134 1 Right Release Latch Bracket (Model 6C4 Only)
12 09P5690 2 Release Latch (Model 6C4 Only)
13 00P4135 1 Left Release Latch Bracket (Model 6C4 Only)
14 00P2805 2 Latch Mounting Bracket (Model 6C4 Only)
15
00P5692 Up to 2 AC Power Supply (Redundant Power Supply is Optional)
09P5859 Up to 2 DC Power Supply (Redundant Power Supply is Optional)
16 N/A 1 Front Power Supply and Processor Assembly Support
Bracket
17 N/A 1 Plastic separator
18 09P5893 1 Processor Filler
19 09P5892 1 Power Supply Filler
20 53P1758 1 PA Port Filter
21 97P3401 2 PA Port Filter Standoffs
Not Shown 42F6841 Up to 2 AC Power Cable, (Power distribution bus to AC power
supply, Model 6C4 only)
Not Shown 00P5691
00P5829
DC Power Cable 3-3 Pin (Model 6C4 only)
DC Power Cable 3-5 Pin (Model 6C4 only)
Not Shown 00P3903 1 Battery (For the battery location refer to “Replacing the
Battery” on page 497.)
Note: See RS/6000 Eserver pSeries Diagnostic Information for Multiple Bus Systems for part numbers.
Chapter 10. Parts Information 519
