FRU Name Physical Location Code AIX Location Code
I/O drawer backplane U0.dd-P1
I/O subsystem drawer U0.dd
RIO Bus Adapter
RIO bus adapter U0.dd-P1.1
RIO port 1 upper connector U0.dd-P1.1/Q1
RIO port 1 cable U0.dd-P1.1/Q1#
RIO port 0 lower connector U0.dd-P1.1/Q2
RIO port 0 cable U0.dd-P1.1/Q2#
PCI Bus Controller
PCI bus controller PHB0 U0.dd-P1
PCI to PCI bridge EADS-X U0.dd-P1 2g-10, 2g-12, 2g-16
PCI Bus Controller PHB2
PCI bus controller PHB2 U0.dd-P1
PCI to PCI bridge (EADS_X) U0.dd-P1 3G-10, 3G-12, 3G-14, 3G-16
Pluggable Adapter Slots
PCI slot 1 U0.dd-P1/I1
PCI card in slot 1 U0.dd-P1-I1 3H-08
PCI slot 2 U0.dd-P1/I2
PCI card in slot 2 U0.dd-P1-I2 3L-08
PCI slot 3 U0.dd-P1/I3
PCI card in slot 3 U0.dd-P1-I3 3S-08
PCI slot 4 U0.dd-P1/I4
PCI card in slot 4 U0.dd-P1-I4 3V-08
PCI slot 5 U0.dd-P1/I5
PCI card in slot 5 U0.dd-P1/I5 2h-08
PCI slot 6 U0.dd-P1/I6
PCI card in slot 6 U0.dd-P1/I6 2m-08
PCI slot 7 U0.dd-P1/I7
PCI card in slot 7 U0.dd-P1/I7 2w–08
Power Supply
Power supply 1 (no internal blower) U0.dd-V1
Power supply 2 (no internal blower) U0.dd-V2
Cooling Blowers
Cooling blower 1 U0.dd-F1
Cooling blower 2 U0.dd-F2
Cooling blower 3 U0.dd-F3
Cooling blower 4 U0.dd-F4
SPCN Connectors
Reserved U0.dd-P1/Q3
Reserved U0.dd-P1/Q4
SPCN3 connector U0.dd-P1/Q5
Chapter 1. Reference Information 37
