IBM System x3650 M4 BD Type 5466 User Manual

Removing the paddle card safety cover (240VA cover)
Use this information to remove the paddle card safety cover (240VA cover) from
the server.
About this task
To remove the paddle card safety cover, complete the following steps.
Procedure
1. Read the safety information that begins on page “Safety” on page vii and
“Installation guidelines” on page 32.
2. Turn off the server (see “Turning off the server” on page 22) and all attached
peripheral devices. Disconnect all power cords; then, disconnect all external
cables as necessary to replace the device.
3. Remove the server top cover (see “Removing the server top cover” on page
258).
4. Remove the screws that secure the safety cover to the chassis and remove the
safety cover.
5. If you are instructed to return the air baffle, follow all packaging instructions,
and use any packaging materials for shipping that are supplied to you.
Figure 191. Screws removal
Chapter 6. Removing and replacing components 263

IBM System x3650 M4 BD Type 5466 Specifications

General

Form Factor	2U Rack
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Memory	Up to 768GB DDR3
Storage	Up to 16x 2.5" hot-swap SAS/SATA HDDs/SSDs
Power Supply	750W
Network Interface	Integrated quad-port Gigabit Ethernet
RAID Support	RAID 0, 1, 10
Remote Management	IBM IMM2
Processor	Intel Xeon E5-2600 v2 series
