IDEC SmartRelay FL1D Series User Manual

Getting started with IDEC SmartRelay
IDEC SmartRelay Manual 10
Expansion modules
The following expansion modules can be connected to the
IDEC SmartRelay:
FL1B-M08B2R2 12/24 V DC 4 digital 4 relays (5A)
FL1B-M08B1S2 24 V DC 4 digital 4 Transistor
24 V / 0.3 A
FL1B-M08D2R2
(1)
24 V AC/DC 4 digital 4 relays (5A)
FL1B-M08C2R2 100...240 V AC/DC
4 digital
(2)
4 relays (5A)
FL1B-J2B2 12/24 V DC 2 analog
0 ... 10 V or
0 ... 20 mA
(3)
none
FL1D-K2B2 24 V DC none
2 analog
0 ... 10 V DC
Symbol Description Supply Voltage Inputs Outputs
(1): Digital inputs can be operated either with P or with N action.
(2): Different phases are not allowed within the inputs.
(3): 0 ... 10 V, 0 ... 20 mA can be connected optionally.
