IDEC SmartRelay FL1D Series User Manual

Getting started with IDEC SmartRelay
9
IDEC SmartRelay Manual
Versions
The following IDEC SmartRelay versions are available:
FL1D-H12RCE 12/24 V DC
8 digital
(1)
4 relays
(10 A)
FL1D-H12SND 24 V DC
8 digital
(1)
4 Transistor
24V / 0.3A
no clock
FL1D-H12RCA
(2)
24 V AC/
24 V DC
8 digital 4 relays
(10A)
FL1D-H12RCC
(3)
100...240 V
AC/DC
8 digital 4 relays
(10A)
FL1D-B12RCE 12/24 V DC
8 digital
(1)
4 relays
(10A)
no display unit
no keyboard
FL1D-B12RCA
(2)
24 V AC /
24 V DC
8 digital 4 relays
(10A)
no display unit
no keyboard
FL1D-B12RCC
(3)
100...240 V
AC/DC
8 digital 4 relays
(10A)
no display unit
no keyboard
Symbol Description Supply
Voltage
Inputs Outputs Properties
(1): Of those can be used alternatively: 2 analog inputs (0 ... 10V) and 2 fast inputs.
(2): The digital inputs can be operated with P or N action.
(3): Two groups consisting of 4 inputs each. Each input within a group must be con-
nected to the same phase. It is possible to interconnect groups with a different
phase.
