IDEC SmartRelay functions
IDEC SmartRelay Manual 214
Parameters V1...V4
The analog values for the parameters V1...V4 can be de-
rived from another, already programmed function. You can
use the actual values of the following functions:
• Analog comparator (actual value Ax - Ay, see Chapter
4.4.18)
• Analog trigger (actual value Ax, see Chapter 4.4.16)
• Analog amplifier (actual value Ax, see Chapter 4.4.20)
• Analog multiplexer (actual value AQ, see Chapter 4.4.26)
• Analog Ramp Control (actual value AQ, see Chapter
4.4.27)
• PI controller (actual value AQ, see Chapter 4.4.28)
and
• Counter (actual value Cnt, see Chapter 4.4.13).
Select the required function by means of the block number.
For information on parameter defaults, refer to Chapter
4.4.1.
Parameter V1...V4: Analog values that
will be issued.
Range of values:
–32768...+32767
p: Number of decimals
Range of values:
0, 1, 2, 3
Output AQ This special function has an
analog output. This output can
only be connected with the
analog input of a function, an
analog memory marker or an
analog output connector
(AQ1, AQ2).
Range of values for AQ:
–32768...+32767
Symbol in
IDEC SmartRelay
Wiring Description
