Technical data
305
IDEC SmartRelay Manual
Delay time at
• 0 to 1
• 1 to 0
typ. 1.5 ms
<1.0 ms (I5, I6)
typ. 1.5 ms
<1.0 ms (I5, I6)
typ. 1.5 ms
typ. 1.5 ms
Line length (unshielded) 100 m 100 m
Analog inputs
Number 2 (I7=AI1, I8=AI2)
Range 0 ... 10 V DC
input impedance
76 k
Ω
Resolution 10 bit, normalized to
0 ... 1000
Cycle time for analog value
generation
300 ms
max. Input voltage 28.8 V DC
Line length (shielded and
twisted)
10 m
Error limit ±1.5 % of full scale
Digital outputs
Number 4 4
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
Dielectric Strength
(between power/input
terminals and output termials)
2,500 V AC, 1minute
500 V DC, 1 minute
2,500 V AC, 1minute
500 V DC, 1 minute
In groups of 1 1
Control of a digital input Yes Yes
Output voltage
Output current
Continuous current I
th
(per ter-
minal)
max. 10 A per relay max. 5 A per relay
Surge current max. 30 A max. 30 A
FL1D-H12RCE
FL1D-B12RCE
FL1B-M08B2R2
