IDS X-Series Installer Manual 700-398-02H Issued July 2013
23
LOCATION 14 Global Options
This location allows you to configure the global options for the X-series Alarm Panel. Table 9 shows
the available options.
NOTE: For each enabled option, the corresponding locations that configure that option must also be
programmed for correct operation.
See Location 19: Extra Global Options for more global options
Table 9: Global Options Data
LED
Default
Action
1
ON
A user assigned to any partition may cancel the siren
2
OFF
Keypad trouble beep
3
OFF
Telephone line monitoring
4
OFF
Keypad beep on successful reporting to the base station
5
ON
Keypad Fire, Medical and Panic keys
6
ON
The display of bypassed and stay zones when armed
7
OFF
Siren delay
8
ON
Box tamper monitoring
9
ON
Siren monitoring
10
OFF
Bus-wired peripheral tamper monitoring*
11
OFF
Onboard dedicated panic– audible
12
ON
Low battery monitoring**
13
ON
Low battery cut-out**
14
OFF
Bypassing with user code
15
OFF
Dedicated panic zone bypassing
16
OFF
Remote transmitters to cancel panic
On = Enable Off = Disable
* Option 9 in location 16 must be enabled for this to work.
** Option 12 needs to be enabled in order for option 13 to work.
NOTE: If mains power is present, then the battery is monitored every 30 minutes.
If mains power is not present, then the battery is monitored every minute. If the battery voltage drops below
10V, then the battery will cut-out if option 13 is enabled. If the battery voltage drops below 11V, then option
12 will be reported if it is enabled.
LOCATION 15 AC Fail / Restore Reporting Delay (default = 0004)
In the event of a power failure (although instantly displaying the trouble indication) the panel will
wait for this period of time before REPORTING the mains failure to the base station This delay eliminates
unnecessary reporting if the AC power is removed for a short time period.
It is important to note that an AC restoral will only be reported if an AC failure was reported first, i.e. the delay
period was exceeded. To program the time into this location:
[INSTALLER CODE] [*] [1] [5] [*] [HHMM] [*]
The valid data range is: 00h01m – 18h00m.
Note: The restoral event is reported and logged within a minute of AC being restored.
LOCATION 16 Trouble Display Enable
This location determines which trouble conditions are indicated on the keypad when viewing the
trouble display. A trouble condition is indicated by a flashing POWER LED. The POWER LED will only stop
flashing once the trouble condition has been cleared. Trouble conditions will be reported if programmed to do
so in locations 571 and 572, regardless of whether or not they are enabled for display.
To view, hold down the [7] key until the keypad beeps. See “Viewing Trouble Conditions” in the User manual.
