LOCATION 36 Zone Status Verify Time (Default = 10min)
This is the time a zone is monitored for a restore. If the zone does not restore, the system will wait the time
entered in this location before sending another burglary event after the siren has timed out.
Note: Must be enabled in Location 221-228 option 8 and the count must be set in location 37
Data entered as mm:ss.
Valid entry is from 00:01 to 59:59.
The default is 10min.
LOCATION 37 Zone Status Verify Count (Default =0)
The number of times a burglary event will be sent if the zone does not restore once the siren times out. After
the number in this location is reached the zone will be ignored until it restores.
Data entered as number count.
Valid entry is from 0 to 16.
Default is 0.
LOCATION 40 Serial Communicator Format
This is to choose which communication format the serial port must communicate with.
Table 19: Communications Format Data
Value
Format Name
Description
0
Ademco Express
Dual Tone HS, DTMF
1
FBI 4 x 2 (With Parity)
1.8kHz TX, 2.3kHz HS, 40PPS
2
FBI 4 x 2 (No Parity)
1.8kHz TX, 2.3kHz HS, 20PPS
3
Silent Knight 4 x 2 Fast
1.9kHz TX, 1.4kHz, 20PPS
4
Silent Knight 4 x 2 Slow
1.9kHz TX, 1.4kHz, 20PPS
5
Contact ID
Dual Tone HS, DTMF
6
SIA Reporting
Bell 103 FSK, HS
TX = Transmit HS = Handshake PPS = Pulses per Second
Note: For serial communication: J1 open = direct download closed = serial reporting enabled
LOCATION 41 Telephone Number 1 Communications Format (default = 5)
The value entered into this location selects the primary communication format. Select from Table 19
the value that corresponds to the required format. During communication, the green LED on the PCB will turn
on indicating that the panel has taken the telephone off-hook. If programmed accordingly, the keypad will
beep after receiving a handshake from the base station. This indicates a successful transmission of data. Refer
to Table 19 for the available communication formats.
[INSTALLER CODE] [*] [4] [1] [*] [COMMUNICATIONS FORMAT] [*]
The valid data range is: 0 – 6. Refer to table 18.
NOTE: Refer to section 0
LOCATION 42 Telephone Number 2 Communications Format (default = 5)
If dual reporting is enabled then this format will be used to report to phone number 2, which
belongs to reporting module 1. Refer to Table 19 for the available communication formats.
[INSTALLER CODE] [*] [4] [2] [*] [COMMUNICATIONS FORMAT] [*]
The valid data range is: 0 – 8.
LOCATION 43 Telephone Number 3 Communications Format (default = 5)
If dual reporting is enabled then this format will be used to report to phone number 3, which
belongs to reporting module 2. Refer to Table 19 for the available communication formats.
[INSTALLER CODE] [*] [4] [3] [*] [COMMUNICATIONS FORMAT] [*]
The valid data range is: 0 – 8.
