IEMCA VIP 80 - Description of Bar Feeder Phase Parameters

59
3
SETUP INFORMATION
302.061
3.1.1 Description of bar feeder phase parameters
Subparameters
It defines the position, speed and acceleration of the bar pusher carriage du-
ring the bar pusher return phase.
Subparameters
It defines the speed, acceleration and direction of the bar pusher carriage du-
ring the zero point research phase.
Subparameters
It defines the bar pusher lifting phase.
46
RETURN
n.46 Phase 1
Spe ed
1500(2000)(mm/ sec )
Pos i t i on
0(mm)
Accel erat i on
3000(mm/ sec*sec )
47
ZERO AX I S
no.47 Phase 2
Re s e a r ch r e l ea s e
30(mm/ sec )
Re s e a r ch s pe ed
100(mm/ sec )
Direct ion
0(mm)
Accel erat i o n
300(mm/ sec*sec)
48
BAR PUSHER UPWARD
no.48 Phase 3
Accel erat i on
300(mm/ sec*sec )
Spe ed
-30(mm/sec)
