3.1.2 Description of reference value parameters
It defines the maximum length of the loadable bar.
This is the 1st feeding stroke value, i.e. the distance between points
0
and
B
.
57
1200(mm)
( inches )
no.57 Max. bar lengh
t
60
1622(mm)
( inches )
no.60 1st FEEDING VA
LUE ( B )
4
2
1
65
7 8
6
9 10
I
II
III
31.014 Ec.3
3
Legend:
I
-
Fixed headstock lathe
II
-
Sliding headstock lathe
III
-
Sliding steady rest lathe
1
-
Carriage “backwards”
2
-
Bar-pusher “backwards”
3
-
Carriage “forwards”
4
-
Short feed door
5
-
Bar-pusher “forwards”
6
-
Spindle
7
-
Headstock “backwards”
8
-
Headstock “forwards”
9
-
Steady rest “backwards”
10
-
Steady rest “forwards”
