PART REPLACEMENT
9
- 55 -
302.028
9.6. SENSOR OF THE SHORT FEED DOOR -
REPLACEMENT
(Fig. 6)
– Open the rear guard.
– Replace sensor
A
keeping 1 mm distance from
came
B
.
6
B A
