USE AND OPERATION
6
- 43 -
302.028
Otherwise, messages showing the operations to
perform will be accordingly displayed.
❏
The bar feeder must shift to the AUTOMATIC
mode, ready to receive the signal from lathe.
Bring the bar feeder to the "BAR FEEDER WAI-
TING" phase.
Press
Should the bar feeder be set, it shifts automatically
in the "BAR FEEDER WAITING" phase.
Otherwise, messages showing the operations to
perform will be accordingly displayed.
6.7. STARTING THE AUTOMATIC CYCLE -
RESUMING WORK FOLLOWING A
SWITCHING OFF
(fig. 9)
❏
If the carriage has been moved while the bar
feeder was not powered:
– Switch on power supply from lathe.
– Press
to start the bar feeder.
– Press
to perform the "BAR FEEDER ZERO
SETTING".
– Bring the carriage to the starting position.
– Press
❏
If the carriage has not been shifted while the
machine was not powered:
– Switch on power supply from lathe.
– Press
to start the bar feeder.
– Press
+
