- 6 -
302.028
2
TECHNICAL SPECIFICATIONS
2.1. DESCRIPTION OF MODELS
VIP 80
bar feeders are available in two models, accor-
ding to the max. length of the bar to feed.
(*)
Model supplied upon request and for special
installations only, to be agreed upon from time to
time.
2.2. GENERAL MACHINE DESCRIPTION
The automatic bar feeder
VIP 80
is used in the
machine-tooling sector and specifically to
automatically feed a lathe.
It can feed either round, hexagonal or square bars
having a max length contained within the lathe spindle
length.
Its working cycle is handled by an integrated PLC in the
control board, which is able to dialogue with the lathe
control system.
The main digital push-button panel makes programming
easier.
The removable additional push-button panel makes it
possible to control the main functions without any need
to move away from the lathe.
Ejection of bar remnants is obtained through either the
bar pusher feed or the next bar feed.
Changing over from one diameter to another is very
easy and fast. It takes only a few minutes.
The bar feeder has been designed so as to allow quick
change of the spindle reduction sleeves.
Model Type Max. bar length (mm)
VIP 80
14 1400
15 (*) 1560
2
2
