IEMCA VIP 80 - Technical Specifications

TECHNICAL SPECIFICATIONS
2
302.028
- 12 -
2.6. TECHNICAL SPECIFICATIONS
(fig. 14)
2.6.1 Noise levels
Usually, the bar feeder does not cause any acoustic
noise during machining, since the bar rotates inside
the lathe spindle.
During the bar feeding, with the bar feeder under normal
conditions, the max. noise peaks average 85 dbA (mea-
surement performed in compliance with the internatio-
nal standards).
Model
14 15
Min. bar diameter ø 5 mm
Max. bar diameter ø 80 mm
Min. bar length 250 mm
Max. bar length 1400 mm 1560 mm
Magazine capacity (working width) 750 mm
Bar pusher diameter ø12 (10) - 15 (12) - 21 (18) mm
Feeding speed (adjustable) MAX 750 mm/s
Return speed (adjustable) MAX 750 mm/s
Bar change-over time 16s
Input voltage 230/400 Volt
Control voltage 24 Volt D.C.
Installed power 1,5 KW
Air pressure 6 bar
Weight 450 kg
14
28_015_2
