IEMCA VIP 80 - Page 141

302.061
Customer Date
Bar feeder model Y/N
Machine tool model
no.
par.
Description of parameters
Default
value
Assigned
value
Page
46
Phase 1 - RETURN
59
Position 0 mm
Speed 1500 mm/sec
Acceleration 3000
mm/sec
2
47
Phase 2 - ZERO AXIS
59
Research speed 100 mm
Release speed 30 mm/sec
Acceleration 300
mm/sec
2
Direction 0
48
Phase 3 - BAR PUSHER UPWARD
59
Speed -30 mm/sec
Acceleration 300
mm/sec
2
49
Phase 4 - BAR LOADING
60
50
Phase 5 - GUIDE CHANNEL LIFTING
60
51
Phase 6 - FIRST FEEDING
60
Position 1621 mm
Speed 100 mm/sec
Acceleration 280
mm/sec
2
52
Phase 7 - RETURN AFTER FIRST FEEDING
61
Position 0 mm
Speed 1500 mm/sec
Acceleration 3000
mm/sec
2
53
Phase 8 -BAR PUSHER DOWNWARD
61
Speed -30 mm/sec
Acceleration 300
mm/sec
2
54
Phase 9 - FACING
61
Position 690 mm
Speed 400 mm/sec
Acceleration 300
mm/sec
2
LIST OF BAR FEEDER PHASE PARAMETERS
B
