ADJUSTMENTS AND SETUP
5
302.028
- 28 -
To be able to carry out the replacement, clear the front
part of the feeder by proceeding as follows:
– Press
to start the feeder.
– Press
to select the manual cycle.
– The feeder can be in two positions:
guide lifted or bar pusher lowered.
Lower the guide or lift the bar pusher.
To lower the guide
press
To lift the bar pusher press
– Open the rear guard (fig. 5).
– Change the reduction sleeves.
– Restore the initial condition.
