Before mounting it, ensure that the gaskets are in the correct position.
In the event component lubrication (already carried out by the manufacturer) is not sucient, remove the residual lubricant
using a dry cloth, then to ease tting coat the parts with common or industrial talc.
7. Mount the cover (A) complete with adaptor (1) and caps (6) on the wall.
8. Assemble the ue to the collective ue exhaust system.
9. Go to the display and through the path Menu/General settings/Menu access level, upon request "Enter password", enter the code 1122
(using knobs "Set DHW" and " Set CH") and press "Ok" aer which, the "Menu access level" menu will open, where you will need to
select the type of access: "Service".
10. Set parameter F.1 = 1.
11. Perform the automatic calibration procedure (Parag.3.10).
Once all components have been assembled properly, the exhaust ue gas will be expelled in the collective ue, the combustion air for
normal appliance operation will be aspirated directly by the sha (Fig. 30).
C
10
≤
C
,
33
Key (Fig. 33):
C - Minimum slope 5%
1
2
3
3
4
5 6 7 6
8
9
A
15
14
13
12
10
11
34
Key (Fig. 34):
e C
(10)
adaptor kit includes:
1 Door adaptor Ø 100 or Ø 125 (1)
No.1 Door gasket made of neoprene (2)
No.4 Screws 4.2 x 9 ST (3)
No.1 Hex headed screw M6 x 20 (4)
No.1 Flat nylon washer M6 (5)
No.2 Door hole closure metal-sheet plate plug (6)
No.1 Plug gasket made of neoprene (7)
No.1 Toothed washer M6 (8)
No.1 M6 nut (9)
e Ø 80/125 extension pipe kit includes:
1 Extension pipe unit Ø 80/125 (10)
e bend kit Ø 80/125 includes:
1 Concentric bend Ø 80/125 at 87° (11)
e non-return valve kit on the ues Ø 80 (12) includes:
1 Gasket Ø 80
1 Non-return valve on ues Ø 80
1 Extension Ø 125
1 Spacer Ø 80 th. 5 mm (to be excluded for this conguration)
No.1 Information sticker
e adaptor kit includes:
4 (kit Ø 80/125) M4 hex headed screws x 16 slotted screwdriver (13)
1 (kit Ø 80/125) Flanged adapter Ø 80/125 (14)
1 (kit Ø 80/125) Concentric gasket (15)
Supplied separately (Fig. 34):
No.1 Ducting kit door (A)
