1 - 13
Transpector MPH Operating Manual
Maximum bakeout temperature for sensors is shown in
Table 1-1.
The Transpector MPH electronics module must be
removed prior to bakeout at temperatures greater than
200°C (FC).
Do not turn on the Electron Multiplier (EM) at sensor
temperatures above 150°C. Turning on the EM at elevated
temperature could result in permanent damage to the
detector.
During or immediately after bakeout, the heating jacket
and metal surfaces in the vicinity of the heating jacket
may be extremely hot. These surfaces may exceed 100°C
at the maximum ambient operating temperature (50°C),
which will cause burns if touched directly without using
the proper personal protection equipment.
Table 1-1 Sensor maximum bakeout temperature
Sensor
Maximum
Operating
Temperature
Maximum Bakeout
Temperature
Electronics Removed
MPH100F/200F/300F 200°C 300°C
MPH100M/200M/300M 150°C 300°C
