Programming manual
Programming peripherals 25
3-6
Wireless transceivers
The Prime/STUDIO software has a section that allows you to view all the enrolled wireless
devices and also configure the programming parameters of each single Air2-BS200
transceiver.
Via softwareClick on the Wireless transceivers button on the menu on the left, the section on the right
will shows a page divided in sections, a section for each configured transceiver.
Each sub-section shows:
• the transceiver model
• the firmware version of the transceiver board
• the transceiver parameters
• a list of devices enrolled by the transceiver;
for each device it shows:
-the Icon
- the terminals (where present)
-the serial number
-the model
3-6-1
Programming transceivers
Table 3-17: Menu bar for wireless transceivers
Key Function
Read
Buttons for reading from and writing on the control panel the data relative the configuration of the
wireless transceivers.
Clicking on these buttons open the “Wireless” window where you can select the transceivers from
those configured.
Write
Clone remote-control
keys
This button starts the guided procedure for cloning the wireless keys enrolled by the transceiver of
the selected board.
The guide allows you to indicate which transceiver, from those selectable, the cloned keys will be
assigned to.
RF
This button starts an operation which attenuates (6db) the wireless signal transmitted by the transceivers for approximately 5 minutes.
During this period the installer can carry out tests on the stability of the RF connection in conditions of poor signal levels.
Table 3-18: Wireless transceiver parameters
Parameter Software section Installer menu section
Channel
Section for the selection of the wireless
communication channel used by the transceiver that
simulates the reader being programmed:
• Channel 001, 868.1MHz
• Channel 002, 868.3MHz
• Channel 003, 868.5MHz
Wireless
transceivers,
Wireless
Readers, ChoosePeriph-
eral, "reader", Channel
Disable tamper
protection
This option disables the Air2-BS200 transceiver
tamper signal.
Readers, ChoosePeriph-
eral, "reader", Op-
tions, Disable Tamper
Disable the Roll-
ing Code
This option disables the rolling code algorithm for the
transmission of wireless commands via the Air2-
BS200 transceiver module.
If the same remote control is used on multiple
systems, the disabling of this feature may be useful
to the installer,
Readers, ChoosePeriph-
eral, "reader", Op-
tions, RollingCodeDisab
