Programming the PrimeLAN board 73
13-2
Graphic maps
The use of the optional PrimeLAN board provides the user with the installation monitoring
function with graphic maps.
By clicking on the PrimeLAN settings button on the menu on the left, you will access the
“Graphic maps” section. Refer to Chapter 20 Graphic map configuration.
Re: (events log)
If this option is enabled, the message text of the event will be saved to the
control panel memory.
If you right click on the header on this column, you will can carry out selections/
deselections which involve all the control panel events or all the events of the
same type.
Recipients
Double clicking on the relative checkbox of the selected event accesses the e-
mail address book.
The Contacts window allows you to select and change the e-mail addresses of
the recipients.
There are 3 buttons:
• Apply - this option allows you to add or delete the recipients of the selected
event only.
• Apply to events of the selected group - this option allows you to add or
delete the recipients of all events of the same type as the selected event.
• Apply to all the selected control panel events - this option allows you to
add or delete the recipient contacts for all the selected control panel events.
Subject
For each event, this option allows you to edit the information provided with the
subject of the e-mail in addition to what is indicated in Table 13-1: E-mail
parameters.
Double-clicking on the checkbox of the relevant event accesses the Message
subject field where you can edit a text:
• if this text filed is left empty, the e-mail subject will also contain the generic
type of event
• if a text is entered, the subject will also include the text specified for the
single event
The 3 buttons Apply, Apply to events of the selected group and Apply to all
the selected control panel events have the same functions as previously
described.
The Set default for selected button automatically configures the object in the
format: “event type - reference”.
If the mouse arrow is positioned on the text body, the contents will be shown as
a tooltip.
Body
This option allows you to edit the text body of the e-mail for each event.
Double click on the respective event field to access the message Text body
window where you can write a text of up to 512 characters on several lines.
You can also add links for direct access to web pages or LAN devices (for
example, IP cameras), in this case, you must always include “http://”.
The 3 buttons Apply, Apply to events of the selected group and Apply to all
the selected control panel events have the same functions as previously
described.
If the mouse arrow is positioned on the text body, the contents will be shown as
a tooltip.
Attachment
This allows you to attach a document/file to the e-mail for each event.
A double click on the checkbox of the selected event accesses the Explore
window where you can load or cancel the selected file from the SD-card.
The 3 buttons Apply, Apply to events of the selected group and Apply to all
the selected control panel events have the same functions as previously
described.
Camera
It is possible to associate a camera to each event.
A double click on the relative field of the selected event will open the Select
Onvif camera window. This window will allow you to select a camera from those
configured and select two presets for it. The presets can be selected from those
listed after updating the dedicated section (refer to paragraph 12-1-2 Shortcut
on event).
The 3 buttons Apply, Apply to events of the selected group and Apply to all
the selected control panel events have the same functions as previously
described.
Record on SD
If enabled, the recorded frames will be saved to the SD card that is inserted into
the PrimeLAN board.
Table 13-2: Email message configuration
