Programming manual
Keypad shortcut and icon 79
Chapter
15
Keypad shortcut and icon
The Prime provides two programming sections for the editing the shortcut icons that appear
on the keypad display in correspondence with keys F1, ..., F12.
The basic icons and association by default with the shortcuts are shown in the table in
Appendix B, Shortcuts by default.
15-1
Icons
Via softwareClick on the Icon button on the menu on the left, the section on the right will provide a grid
with the 80 available icons. Of these the last 30 are “blank” icon spaces.
Selecting one of these blank spaces opens a page where it is possible to edit:
• Description, the descriptive string associated with the icon.
• You can change the design of the icon by means of digital graphic tools.
15-2
Association shortcut-icon
Via softwareClick on the Association shortcut-icon button on the menu on the left, the section on the
right will provide a grid with all the 38 available shortcuts and their associated icons.
The selection of one of these icons opens a section in the lower part of the screen showing all
the 80 icons and their descriptions. Clicking on any one of these associates it with the selected
shortcut.
Via keypad1. Accessing the “Shortcuts” section:
Type-in Code
(Installer)
, PROGRAMMING Shortcuts
2. Use keys and to select the shortcut then press OK.
Set the parameters:
• Description - this is the descriptive string of the shortcut which can be customized by the
installer.
• Icon - this section allows you to select the icon you want to associate with the shortcut, by
indicating the icon number
3. Use keys and to scroll across the digits of the number.
4. Use the number keys to edit the number.
5. Press OK to confirm and exit.
