74 Programming the PrimeLAN board
Anti-intrusion control panels
13-3
ONVIF cameras
Remote ZTL control and preset audio/video profiles allow hassle-free user interaction with
ONVIF protocol cameras.
The PrimeLAN board provides support for JPEG and MJPEG streams for surveillance cameras
and allows users to retrieve and view video recordings and snapshots. Interaction with ONVIF
cameras allows viewing of recorded images (videos and snapshots) previous to and after the
occurrence of an event.
The frames are sent as attachments to emails associated with events or are stored for viewing
using a web interface or AlienMobile application, through the “Camera” section.
To do this it is necessary to:
• program the ONVIF camera (using its own presets), provide it with the ZTL presets
necessary for viewing the zone under surveillance and recorded video
• associate a camera with the occurrence (activation or restoral) of an event through the
Email configuration section (refer to paragraph 13-1 Programming e-mails)
•activate the Record on SD option (refer to paragraph 13-1 Programming e-mails) for the
viewing of recorded frames through a web interface
• using the Prime/STUDIO software, configure the ONVIF camera by clicking-on the
PrimeLAN settings button and then going to the“Programming - ONVIF camera
management” section on the right.
This section provides a pane containing the list of the configured cameras. At the side of this is
another section containing the parameters relative to the selected camera:
Table 13-3: ONVIF camera parameters
Parameter Software section
Buttons for the addition of a new camera or for the deletion of the selected
camera.
ONVIF camera
management
Include Security
Header in messages
This option, if enabled, includes the “Security Header” in the SOAP messages for
the communication with Onvif devices.
Description
This is the description of the selected camera.
ONVIF camera
management,
Camera
IP address
Port
User name
Password
Parameter that permits access to the selected camera.
https
If selected, a secure HTTPS connection will be used.
Multimedial profile
Field for the selection of one of the multimedia profiles of the camera. These
profiles are listed following a read operation requested by pressing the
button.
The button opens a window showing all the available profiles and where you
can edit the “Token” and name of each one.
The window provides two buttons:
• - for manual entry of a profile in the list
• - for deletion of the selected profile
Pan - Tilt - Zoom
This field indicates whether the selected camera is equipped with PTZ (Pan, Tilt,
Zoom) capabilities.
Preset available for
the selected profile
This section lists all the presets relating to the profile selected in the previously
mentioned programming field. These presets are listed following a read operation
requested by pressing the button.
The button opens a window showing all the available presets and where you
can edit the “Token” and name of each one.
The window provides two buttons:
• - for manual entry of a preset in the list
• - for deletion of the selected preset
URI Snapshot
URI Stream
This field allows you to view the addresses (URIs) of frames shots and audio/
video streams. These addresses are listed following read operation requested by
pressing the button.
Sampling frequency
This is the time that must elapse between two successive frame shots (max. 60
seconds).
Number of frames
pre/post event
This is the number of frames (from 0 to 5) which will be saved to the memory
before/after the occurrence of the event the camera is associated with.
Images
The image in the lower part of the section reproduces the instant frame of the
camera selected after pressing the button.
Clicking on the image itself opens window for the viewing of video footage in
real-time, control of the camera functions and display of the available presets.
