Programming manual
Programming peripherals 17
The button enables the wireless attribute on the terminal (and consequently on the
entire expansion). The “Wireless” string will be shown on the line at the bottom of the display.
Pressing the button again will disable the wireless attribute on the terminal (and
consequently the entire expansion).
3-3-2
Programming expansions
The programming of expansions as Prime system peripherals can be carried out via software
or from a keypad.
Via softwareBy clicking on the Expansions button on the menu on the left, the section on the right will
show a list of the configured expansions. Selecting one of the options will allow you configure
the parameters of the single expansion by clicking on the button.
Via keypad Type in Code (Installer) , PROGRAMMING Expansions, ChoosePeripheral
This section allows the programming of the various options of the selected expansion.
3-3-3
Expansion parameters
3-4
Sounders/Flashers
3-4-1
Enrolling sounders/flashers
Via softwareOnce the solution for the system to be designed has been opened, click on the System
Layout button on the menu on the left. Then click on the “Add device to BUS” button in the
section on the right.
A window will open where it is possible to select the sounders/flashers to be configured and
added to the configuration.
In the section on the left the number increases in correspondence with the sounders/flashers
button.
To remove a sounder/flasher from the structure, click on the relative button on the menu on
the left to access the programming section, then, from the list that appears, click on the
Delete button that corresponds to the line of the sounder/flasher in question.
Via keypad Type-in Code (Installer PIN), PROGRAMMING Sounders/Flashers, Enablements
In this section it is possible to add/remove sounders/flashers from the configuration by means
of keys and .
WIRELESS
SOUNDERS/
FLASHERS
The Prime system provides guided procedures for the enrolling of wireless sounders/flashers.
Via softwareBy clicking on the Sounders button in the menu on the left, it will be possible to select a
sounder/flasher from the “Programming - Configured sounders/flashers” section.
The checkbox next to that of the sounder/flasher description allows the selection of the
sounder/flasher type:
- Hardwired sounder/flasher
- Indoor wireless sounder/flasher
- Outdoor wireless sounder/flasher
Terminals 12345
EXPAN. XYZ IIII
Expans. XYZ T01
Wireless
Table 3-8: Individual expansion parameters
Parameter Software section Installer menu section
Description
Description string of the expansion (to be customized
by the installer).
Configured
expansions,
selected expansion
Expansions, ChoosePe-
ripheral, "expansion"
Sound on output
This option that enables/disables the buzzer of the
selected expansion when the relevant T1 terminal is
activated as an output.
Expansions, ChoosePe-
ripheral, "expansion",
Options
Disable tamper
protection
This option enables/disables tamper on the peripheral
(enabled by default).
