26 Programming peripherals
Anti-intrusion control panels
3-7
Temperature sensors
3-7-1
Enrolling temperature sensors
Via software Once the solution for the system to be designed has been opened, click on the System
Layout button on the menu on the left. Then click on the “Add device to BUS” button in the
section on the right.
A window will open where you can select the temperature sensors to be configured and added
to the configuration.
In the section on the left the number increases in correspondence with the temperature
sensors button.
To remove a sensor from the structure, it is necessary to access the programming section by
clicking on the relative button in the menu on the left then, from the list shown, click on the
Delete button in correspondence with the line of the sensor to be removed.
Via keypad
Type in Code
(Installer)
, PROGRAMMING EnrolPeripherals
This section will allow you to carry out the enrolling process in two different ways:
• by manually entering the 14-digit serial code shown on the temperature sensor package;
• by pressing the ENROLL button on the temperature sensor.
Following this operation, the temperature sensor will transfer the serial code to the control
panel.
Note
All the letters entered for the code must be uppercase.
The control panel will offer the first free address for the type of peripheral identified. The
installer can change this address as desired or confirm it by pressing the OK button.
After which, you can enable or disable the enrolled probes via the menu option:
Type-in Code
(Installer),
PROGRAMMING TemperatureProbes, Enablements
This section allows you to add/remove probes from the configuration by means of keys
and .
3-7-2
Programming temperature sensors
The programming of temperature sensors as Prime system peripherals can be carried out
either via software or from a keypad.
Via software Click on the Temperature sensors button on the menu on the left, the section on the right
will provide the list of configured temperature sensors.
Selecting one of the options will allow you to configure the parameters of the single reader by
clicking on the button.
Via keypad
Type in Code
(Installer)
, PROGRAMMING TemperatureSens., ChoosePeripheral
This section allows you to program the various options of the selected temperature sensor.
3-7-3
Temperature sensor parameters
Table 3-19: Individual sensor parameters
Parameter Software section Installer menu section
